Programming technology functions (cycles)
9.5 Contour milling
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
533
Note
The following error messages can occur when chamfering inside contours:
Safety clearance in the program header too large
This error message appears when chamfering would, in principle, be possible w
ith the
parameters entered for FS and ZFS, but the safety clearance then could not be
maintained.
Immersion depth too large
This error message appears when chamfering would be possible through the reduction of
the immersion depth ZFS.
Tool diameter too large
This error message appears when the tool would already damage the edges during
insertion. In this case, the chamfer FS must be reduced.
For solid machining residual material, you require the option "residual material
detection and machining".
For multi-channel systems, cycles attach a "_C" and a two-digit number of the specific
channel to the names of the programs to be generated, e.g. for channel 1 "_C01". This is the
reason that the name of the main program must not end with "_C" and a two-digit number.
This is monitored by the cycles.
For single-channel systems, cycles do not extend the name of the programs to be
generated.
Note
G code programs
For G code programs, the programs to be generated, which do not include any path data,
are saved in the directory in which the main program is located. In this
case, it must be
ensured that programs, which already exist in the directory and which have the same name
as the programs to be generated, are overwritten.
