Programming technology functions (cycles)
9.6 Further cycles and functions
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
569
equire the software option in order to use this function:
With the "High Speed Settings" function, you can select between four technological
machining types:
● "Finishing"
● "Rough-finishing"
● "Roughing"
● "Deselected" (default setting)
Note
Plain text entry
You can enter the parameters in plain text in the "Machining" selection box.
Plain text is generated for the "Machining mode" parameter when the input screen is
closed.
For CAM programs in the HSC range, the four machining types directly relate to the
accuracy and speed of the path contour (see help screen).
The operator/programmer uses the tolerance value to give a corresponding weighting.
Corresponding to the appropriate G commands, the four machining types are assigned to
technology G group 59:
Finishing DYNFINISH
You can enter the orientation tolerance for applications on machines with the dynamic multi-
axis orientation transformation (TRAORI).
Additional G commands that are available in conjunction with machining free-form surfaces,
are also activated in the High Speed Settings cycle.
When deselecting CYCLE832, the G groups are programmed to the settings - during the
program run time - that are declared in the machine data for the reset state.
