Programming technology functions (cycles)
9.6 Further cycles and functions
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
571
Machining
• ∇ (roughing)
Plain text: _ROUGH
• ∇∇ (semi-finishing)
Plain text: _SEMIFIN
• ∇∇∇ (finishing)
Plain text entry: _FINISH
• Deselection
For "Multi-axis programming yes", the following plain texts are generated in accord-
ance with the machining type:
• ∇ (roughing) with input of the orientation tolerance
Plain text: _ORI_ROUGH
• ∇∇ (semi-finishing) with input of the orientation tolerance
Plain text entry: _ORI_SEMIFIN
• ∇∇∇ (finishing) with input of the orientation tolerance
Plain text entry: _ORI_FINISH
Tolerance of the machining axis
Multi-axis
program
Multi-axis program for 5-axis machines
• Yes
The orientation tolerance >0 degrees can be entered here
• No
The value 1 is entered automatically
The field can be hidden.
Please observe the machine manufacturer’s instructions.
