Programming technology functions (cycles)
9.7 Additional cycles and functions in ShopTurn
Turning
594 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Parameters
Description
Unit
X
Y
I
J
Machining plane face C
Target position X ∅ (abs) or target position X referred to the last programmed
position (inc)
Target position Y (abs) or target position Y referred to the last programmed posi-
tion (inc)
Circle center point I (ink)
Circle center point J (inc)
Note:
Incremental dimension: The sign is also evaluated.
mm
mm
mm
mm
X
Y
I
J
Machining plane face Y
Target position X (abs) or target position X referred to the last programmed posi-
tion (inc)
Target position Y (abs) or target position Y referred to the last programmed posi-
tion (inc)
Circle center point I (inc).
Circle center point J (inc).
Note:
Incremental dimension: The sign is also evaluated.
mm
mm
mm
mm
X
Z
I
K
Machining plane rotation
Target position X ∅ (abs) or target position Y referred to the last programmed
position (inc)
Target position Z (abs) or target position X referred to the last programmed posi-
tion (inc)
Circle center point I (ink).
Circle center point K (inc)
Note:
Incremental dimension: The sign is also evaluated.
mm
mm
mm
mm
F Machining feedrate mm/rev
mm/min
mm/tooth
