Siemens SINUMERIK 828D - Page 637

Multi-channel machining
10.2 Multi-channel support
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
637
Settings for a program block
Display
Meaning
Text
Block designation
Spindle
• S1
• S2
Spindle assignment. Defines at which spindle a program block is to be ex-
ecuted.
Addit. run-in code
• Yes
For the case that the block is not executed, as the specified spindle should
not be considered when running in, then it is possible to temporarily acti-
vate what is known as "Addit. run-in code".
• No
Automat. retraction
• Yes
Block start and block end are moved to the tool change point, i.e. the tool
is retracted.
• No
Procedure
1.
Select the "Program manager" operating area.
2.
Select the storage loc
ation and create a program or open a program.
The program editor opens.
3.
Select the required program blocks, which you wish to combine to form
a block.
4.
Press the "Build group" softkey.
The "Build group" window is opened.
5.
Enter a designation for the block, assign the spindle, if required, select
the Addit. run
-in code and the automatic retraction and then press the
"OK" softkey.
