Tool management

12.11 Filtering the tool management lists

Turning

714 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

Procedure

Select the "Parameter" operating area.

...

Press the "Tool list", "Tool wear" or "Magazine" softkey.

...

Press the ">>" and "Filter" softkeys.

The "Filter"

window opens.

Activate the required filter criterion and press the "OK" softkey.

The

tools that correspond to the selection criteria are displayed in the

list.

The active filter is displayed in the window header.
