Tool management

12.14 Settings for tool lists

Turning

Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

719

Procedure

1.

Select the "Parameter" operating area.

...

2.

Press the "Tool list", "Tool wear" or "Magazine" softkey.

3.

Press the "Continue" and "Settings" softkey

s.

4.

Activate the corresponding check box for the desired setting.
