Managing programs
13.1 Overview
Turning
732 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Data exchange with other workstations
You have the following options for exchanging programs and data with other workstations:
● USB drives (e.g. USB-FlashDrive)
● Network drives
● FTP drive
Choosing storage locations
In the horizontal softkey bar, you can select the storage location that contains the directories
and programs that you want to display. In addition to the "NC" softkey, via which the file
system data can be displayed, additional softkeys can be displayed.
The "USB" softkey is only operational when an external storage medium is connected (e.g.
USB-FlashDrive on the USB port of the operator panel).
Displaying documents
You can display documents on all drives of the program manager (e.g. in the local drive or
USB) and via the data tree of the system data. Various data formats are supported:
● PDF
● HTML
It is not possible to preview HTML documents.
● Various graphic formats (e.g. BMP or JPEG)
● DXF
Software options
You require the "DXF reader" option in order to display DXF files.
Note
FTP drive
It is not possible to preview documents on the FTP.
Structure of the directories
In the overview, the symbols in the left-hand column have the following meaning:
Directory
Program
