Managing programs

13.3 Executing a program

Turning

Operating Manual, 01/2015, 6FC5398-8CP40-5BA2

741

If the selected program is already opened in the "Program" opera

ting

area,

Press the "Execute NC" softkey.

Press the <CYCLE START> key.

Execution of the workpiece is started.

Note

Program selection from external media

If you execute programs from an external drive (e.g. network drive), you require the

"Execution from Exte

rnal Storage (EES)" software option.
