Siemens SINUMERIK 828D User Manual

Managing programs
13.17 Setup data
Turning
780 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Procedure
1.
Select the "Program Manager" operating area.
2.
Position the cursor on the file with the backed
-up tool and zero point
data (
*.INI) that you wish to re-import.
3.
Press the <Cursor right> key
- OR -
Double-click the file.
The "Read-in setup data" window opens.
4.
Select the data (e.g. magazine assignm
ent) that you wish to read-in.
5.
Press the "OK" softkey.

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
