Working with a B axis (only 840D sl)
16.5 Approach/retraction
Turning
Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
829
Parameter
Description
Unit
F1 Feedrate to approach the first position
Alternatively, rapid traverse
mm/min
X1
1. position (inc or ∅ abs)
mm
Z1
1. position (inc or ∅ abs)
mm
Y1 Retraction to safety clearance mm
β2
Beta angle for 1st swivel movement
Degrees
γ2
Gamma angle for 1st swivel movement
Degrees
Tracking The position of the tool tip is maintained during swiveling.
Please refer to the machine manufacturer's instructions.
F3 Feedrate to approach the third position
Alternatively, rapid traverse
mm/min
X3
3. position (inc or ∅ abs)
mm
Z3
3. position (inc or ∅ abs)
mm
Tool change
• TlChngPt: Approach the tool change point from the last programmed position
and carry out a tool change
• Direct: Tool is not changed at the tool change position, but at the last pro-
grammed position
• No: Tool is not changed
T
Tool name (not for tool change "no")
D
Cutting edge number (not for tool change "no")
F4 Feedrate for approach to the fourth position
Alternatively, rapid traverse
mm/min
X4
4. position (inc or ∅ abs)
mm
Z4
4. position (inc or ∅ abs)
mm
β5
Beta angle for 2nd swivel movement
Degrees
γ5
Gamma angle for 2nd swivel movement
Degrees
Tracking The position of the tool tip is maintained during swiveling.
Please refer to the machine manufacturer's instructions.
F6 Feedrate to approach the sixth position
Alternatively, rapid traverse
mm/min
X6
6. position (inc or ∅ abs)
mm
Z6
6. position (inc or ∅ abs)
mm
Y6
Retraction to safety clearance
mm
