Working with a B axis (only 840D sl)
16.8 Measuring a tool with the B axis
Turning
834 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
If you do not wish to keep the tool at the workpiece edge, then press
the "Save position" softkey.
The tool position is saved and the tool can be retracted from the wor
k-
piece. For instance, this can be practical i
f the workpiece diameter still
has to be subsequently measured.
If the tool can remain at the workpiece edge, then after scratching you
can directly continue with step 7.
Enter the position of the workpiece edge in X0 or Z0.
If no value is entered for
X0 or Z0, the value is taken from the actual
Press the "Set length" sof
tkey.
The tool length is calculated automatically and entered in the tool list.
Whereby the cutting edge position and tool radius or diameter are a
u-
tomatically taken into consideration as well.
Note
Tool measurement is only possible with an active too
l.
T,S,M window (Page 109)
Measuring a tool manually (Page 78)
