Siemens SINUMERIK 828D - Page 884

Service Planner (828D only)
23.2 Set maintenance tasks
Turning
884 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Procedure
1.
Select the "Diagnostics" operating area.
2.
Press the menu forward key
and then the "Service planner" softkey.
The window opens and displays a list of all the tasks that have been set
up.
The values cannot be edited.
3.
Press the "New maintenance tas
k" softkey to set up a new mainte
nance
task.
A message informs you that a new maintenance task will be set up at
the next free position. Enter the required data in the columns and press
the "OK" softkey.
- OR -
Position the cursor on the desired maintenance task and press the
"Change task" softkey to change the associated times.
All columns except Remaining time and Status can be edited.
- OR -
Press the "Reset all" softke
y to reset all the times.
- OR -
Position the cursor on the desired maintenance task
and press the "De-
lete task" softkey to remove the maintenance task from the list.
