Siemens SINUMERIK 828D User Manual

Edit PLC user program (828D only)
24.3 Structure of the user interface
Turning
888 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
Table 24- 1 Key to screen layout
Screen element
Display
Meaning
1
Application area
2 Supported PLC program language
*
Program change exists
3 Name of the active program block
Representation: Symbolic name (absolute name)
4 Program status
Run
Program is running
Stop
Program is stopped
Status of the application area
Sym
Symbolic representation
Abs
Absolute representation
5 Display of the active keys (<INPUT>, <SELECT>)
6 Focus
Performs the tasks of the cursor
7 Information line
Displays information, e.g. for searching

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
