Independent Key Transitions 117
Chapter
3
Signal
Selection
and
Transitions
Setting the Independent Key
Transition Rate
There are two ways of setting the transition rate: using the
Flexi Pad control block, Multifunction Flexi Pad control
block or numeric keypad control block to enter a numeric
value, or using the Key menu to access the Transition
menu for the M/E or PGM/PST bank.
You can also display the transition rate, independent key
transition rate, and fade-to-black transition rate for each of
the M/E and PGM/PST banks, and change the settings (see
page 234).
When the setup selection is for separate transition rates for
inserting or deleting a key, you can set both rates
independently. For example, with the system in the state
with the key not inserted, the transition rate setting applies
to key insertion.
Setting the independent key transition rate
in the Flexi Pad control block
Notes
In the PGM/PST bank or when using a simple-type
transition control block, you cannot use the Flexi Pad
control block to set the transition rate.
1
In the Flexi Pad control block of the M/E bank, hold
down the [TRANS RATE] button, and in the
independent key transition control block, press the
delegation button [KEY1] to [KEY8] for the key for
which you want to set the transition rate.
The memory recall section display is now ready to
accept the entered independent key transition rate.
2
Enter the desired transition rate with the numeric
keypad.
•
Enter a value of up to three digits.
•
To cancel the entry, press any of the six buttons in
the leftmost column ([WIPE], [DME], …) or the
[TRANS RATE] button.
For details of frame input mode and timecode input
mode, see page 105.
3
Press the [ENTR] button.
Setting the independent key transition rate
in the numeric keypad control block
Notes
You cannot use the numeric keypad control block to set the
transition rate for a simple transition.
1
In the numeric keypad control block, hold down the
[TRANS RATE] button, and in the independent key
transition control block, press the delegation button
[KEY1] to [KEY8] ([DSK1] to [DSK8] in the PGM/
PST bank) for the key for which you want to set the
transition rate.
The numeric keypad control block changes to the
mode for inputting the independent key transition rate,
and its display now shows the corresponding region
name and the current transition rate set for the region.
2
With the numeric keypad, enter the transition rate.
•
Enter a value of up to three digits.
•
To clear the entry value, press the [CLR] button.
For details of frame input mode and timecode input
mode, see page 105.
3
Press the [ENTER] button.
This confirms the entry, and the selected region name
and the set transition rate appear in the numeric keypad
control block display.
To enter a difference from the current value
After pressing the [+/–] button, enter the difference and
press the [TRIM] button.
To change the sign (+ or –), press the [+/–] button.
Setting the independent key transition rate
in the Multifunction Flexi Pad control block
For example, to set the independent key transition rate for
M/E-1 key1, carry out the following procedures.
1
In the Multifunction Flexi Pad control block, press the
[TRANS RATE] button.
The Multifunction Flexi Pad control block switches to
the transition rate setting mode.
2
In the region selection buttons, select the switcher
bank.
3
Press the [TRNS SEL] button in the memory recall
section.
You can select the type of transition for which to set
the rate.
4
Press the [KEY1] button.
This enables setting of the independent key transition
rate for M/E-1 key1.
5
Watching the alphanumeric display, enter the
transition rate you want to set with the memory recall
section button.
To Next Page
