Sony MVS-8000X SystemMVS-7000X System - Split Settings; Split Slide Settings

USO RESTRITO
Applying Special Effects (Nonlinear Effect Settings) 321
Knob
Parameter
Adjustment
Setting values
2
V
Degree of
top and
bottom
separation
–3.000 to +3.000
a)
–12.000 to
b)
Knob
Parameter
Adjustment
Setting values
1
Transition H
Degree of
transition in
horizontal
direction
–100.00 to
+100.000
2
Random H
Degree of
randomness in
distance
moved by
blocks in
horizontal
direction
0.00 to 100.00
3
Skew H
Degree of skew
in horizontal
direction
0.00 to 100.00
4
Width H
Horizontal
width of
partition
0.00 to 100.00
5
Angle
Angle of
partition line
–8.000 to
+8.000
Knob
Parameter
Adjustment
Setting values
1
Top
Amount of
movement of
top
–100.00 to
+100.000
2
Left
Amount of
movement of
left
–100.00 to
+100.000
3
Right
Amount of
movement of
right
–100.00 to
+100.000
4
Bottom
Amount of
movement of
bottom
–100.00 to
+100.000
Knob
Parameter
Adjustment
Setting values
1
Transition V
Degree of
transition in
vertical
direction
–100.00 to
+100.000
2
Random V
Degree of
randomness in
distance
moved by
blocks in
vertical
direction
0.00 to 100.00
3
Skew V
Degree of skew
in vertical
direction
0.00 to 100.00
Chapter
11
DME
Operations
a) Setting for SD 4:3, SD 16:9
b) Setting for HD 4:3, HD 16:9
Split Settings
You can set the degree to which the image is split, the split
positions, and other parameters.
a) Setting for SD 4:3, SD 16:9
b) Setting for HD 4:3, HD 16:9
+12.000
To apply the Split effect
With the Split menu displayed, use the following
procedure.
1 In the <Mode> group, select the split method.
Single: Leave gaps between splits.
Double: Fill gaps between splits with the same image.
2 Set the following parameters.
Parameter group [1/2]
Split Slide Settings
You can set the degree of transition, the degree of
randomness in the distance moved by each block, the
degree of sliding, block width, block angle, and other
parameters.
To apply the Split Slide effect
With the Split Slide menu displayed, set the following
parameters.
Parameter group [1/2]
Knob
Parameter
Adjustment
Setting values
1
Transition
H
Degree of
left and right
separation
–100.00 to
+100.000
2
Transition
V
Degree of
top and
bottom
separation
–100.00 to
+100.000
Parameter group [2/2]
Parameter group [2/2]
To set the split position
1 Press [Position].
2 Set the following parameters.
Knob
Parameter
Adjustment
Setting values
1
H
Degree of
left and right
separation
–4.000 to +4.000
a)
–16.000 to
+16.000
b)
