Chapter
2
Menus
and
Control
Panel
To switch the subsidiary menu site on and
off
Assign [SUB MENU SITE] to a menu control block top
menu selection button or user preference button.
To switch to the subsidiary menu site, press this button,
turning it on.
For details, see “Assigning Functions to the Menu Control
Block Top Menu and User Preference buttons” in Chapter
19 (Volume 2).
Going Back to the Previous Menu
To return to the last displayed menu, press the previous
page button.
Returning to Default State in
Function Groupings
1
Press [Default Recall], turning it on.
This enters the menu default recall mode.
2
Press the VF button you want to return to the default
state.
This returns the settings within the function grouping
to the default state, and [Default Recall] goes off.
Notes
The default state of the settings depends on the setting of
the initial status mode, set in the Setup menu of system
setup, as follows.
User: The state when [Initial Status Define] is executed.
Factory: Factory default settings
Notes
The default recall function does not return the horizontal
(H) and vertical (V) position settings to their default state
individually. Returning the horizontal (H) position to its
default state also returns the vertical (V) position to its
default state automatically, and vice versa.
Operation With a Mouse
If you display the menus in an external monitor, operated
with a mouse, then you click the mouse instead of pressing
a button as described in the previous section, “Menu
Operations.”
However, in the following cases there are special
operations with a mouse.
To set a parameter with the mouse
To adjust the value of a knob setting parameter button with
the mouse, you can use any of the following three methods.
•
Position the cursor over the knob setting parameter
button for which you want to adjust the value, and turn
the mouse wheel.
•
Position the cursor over the knob setting parameter
button for which you want to adjust the value, then hold
down the right mouse button, and drag the bar showing
the setting to the desired value.
•
Position the cursor over the knob setting parameter
button for which you want to adjust the value, then click
the left mouse button to open the numeric keypad
window by which you can input the desired value.
To scroll a list with the mouse
Position the cursor over the list you want to scroll, and turn
the mouse wheel.
In the setup menus you can select the direction of mouse
wheel rotation that increases the setting value. And you
can also switch the functions of the right and left mouse
Returning Knob Parameters to
Default State
1
Press [Default Recall], turning it on.
This enters the menu default recall mode.
2
Press the knob parameter button you want to return to
the default state.
This returns the knob parameter value to the default
state, and [Default Recall] goes off.
For details, see the table, “Knob parameters subject to
restriction on default recall” on page 407.
buttons.
For details, see Chapter 19 “Setting the Mouse Wheel
Scrolling Direction for Parameter Setting” (Volume 2).
