Router Interface Settings (Router Menu) 653
4
In the <Device> group, select [External Box2].
5
In the <Matrix Size> group, select [32×1].
6
Turn the knobs to make adjustments.
At this point make the settings of Destination and
Level the same as in step 3.
Chapter
23
Setup
Relating
to
Router
Interface
and
Tally
(Router/Tally)
Setting External Boxes 1 to 12
1 In the Router/Tally >Router menu, press [External
Box Assign].
The External Box Assign menu appears.
2 In the <Device> group, select what the setting applies
to (one of External Box 1 to 12).
3 In the <Matrix Size> group, select the number of
inputs for the external box.
No Assign: Do not use.
4×1: 4 inputs and 1 output.
8×1: 8 inputs and 1 output.
16×1: 16 inputs and 1 output.
32×1: 32 inputs and 1 output.
Notes
The maximum total number of inputs for all 12
external boxes is 102.
4 Turn the knobs to make adjustments.
Knob
Parameter
Adjustment
Setting values
1
Source
Source start
address
1 to 1021
a)
1 to 1017
b)
1 to 1009
c)
1 to 993
d)
2
Destination
Destination
start address
1 to 1024
3
Level
Level
1 to 8
a) When Matrix Size is 4×1
b) When Matrix Size is 8×1
c) When Matrix Size is 16×1
d) When Matrix Size is 32×1
Coupling external boxes
By coupling a number of external boxes, the number of
inputs can be increased.
Here the example of coupling External Box1 and External
Box2 is described.
1 In the Router/Tally >Router >External Box Assign
menu, select [External Box1] from the <Device>
group.
2 In the <Matrix Size> group, select [8×1].
3 Turn the knobs to make adjustments.
Knob
Parameter
Adjustment
Setting values
1
Source
Source start
address
1 to 1017
2
Destination
Destination start
address
1 to 1024
3
Level
Level
1 to 8
This automatically couples External Box1 and
External Box2, forming an external box with 40
(8+32) inputs.
Setting the group number of an S-Bus
description name
1 In the <Alias Name Gp> group of the Router/Tally
>Router menu, press [Gp No].
2 Turn the knob to set the following parameter.
Knob
Parameter
Adjustment
Setting values
1
Gp No
Group number of
S-Bus description
name
0 to 7
a)
a) When a setting value of 1 to 7 is selected: If the name is not set, the
description name for “0” appears.
If the description name for “0” is not registered either, the Type and
No values appear.
3 In the <Alias Name Gp> group, press [Set].
This confirms the setting, which is reflected in the
status area.
Notes
Transmit the description name selected here from the
router.
