Overall Control Panel Settings (Config Menu)
Select keyer to be
master
Chapter
19
Control
Panel
Setup
(Panel)
•
Press the arrow keys to scroll the reverse video
cursor.
•
Turn the knob.
The selected keyer appears in reverse video.
4
In the <Key Select> group, select the keyer to be
linked to the transition of the master.
Notes
Linking does not apply to a transition carried out with
the downstream key control block.
Linking the Next Transition Selection
Buttons
To the transition links between keyers, you can add a link
for the next transition selection buttons in the transition
control block. The effect of this additional link is such that
if for example, two keyers (Key 2 and Key 3) are linked
with the master keyer (Key 1), pressing the [KEY1] next
transition selection button also selects the [KEY2] and
[KEY3] buttons.
1
Set the transition links between keyers.
For details of the operation, see the previous section
“Linking Transitions Between Keyers.”
2
Press [Next Trans Link], turning it on.
The [KEY1] to [KEY8] next transition selection
buttons in the transition control block are now selected
coupled to the settings in the Key Trans Link menu for
transition links between keyers.
Notes
These settings apply to the whole Key Trans Link
menu. It is not possible to make separate settings for
each master keyer.
Selecting the Module to Be the
Reference for Device Control Block
When both trackball and joystick device control blocks are
connected, select which is to be the reference. Also select
the range to which key wipe positioning applies.
To select the reference module
1
In the Panel >Config menu, press [JS/TB User
Setting].
The JS/TB User Setting menu appears.
2
In the <Reference Module> group, select one of the
following.
Trackball: Trackball device control block
Joystick: Joystick device control block
To select the range to which key wipe
positioning applies
In the Panel >Config menu <Wipe Pos Key Select
Module> group, select one of the following.
KEY1-4: Applies to keys 1 to 4.
KEY1-8: Applies to keys 1 to 8.
Notes
When “KEY1-8” is selected, after selecting more than one
key it is not possible to carry out key wipe positioning.
There is no such restriction when “KEY1-4” is selected.
Assigning a Region to the Region
Selection Buttons in the Numeric
Keypad Control Block or
Multifunction Flexi Pad Control
Block
You can set a maximum of four regions to each of the
region selection buttons in the numeric keypad control
block or Multifunction Flexi Pad control block.
In the Multifunction Flexi Pad control block, pressing the
region selection button [MORE] displays the regions not
assigned to the region selection buttons on the memory
recall section numeric keypad buttons, so that you can
select them, and set the assignment of regions to the
numeric keypad buttons.
However, in the Multifunction Flexi Pad control block, it
is not possible to assign a region to the [EXIT] button.
1 In the Panel >Config menu, press [10 Key Region
Assign].
The 10 Key Region Assign menu appears.
To Next Page
