Settings Relating to Function Links (Link Menu)
Knob
Parameter
Adjustment
Setting values
1
GPI Port
GPI output port
selection
1 to 8
Knob
Parameter
Adjustment
Setting values
1
GPI Port
GPI output port
selection
1 to 8
2
Link No
Link number
selection
1 to 8
3
Video/
Button No
Selection of
video or button
name to be
linked
1 to maximum
a)
Chapter
20
Switcher
Setup
(Switcher)
Disable: Disable the GPI link setting for the selected
bus.
All Enable: Enable the GPI link setting for all buses.
3 Press [GPI Link Adjust].
The GPI Link Adjust menu appears.
The status area shows the current setting state of the
selected link, and a list of the selectable video names
or button names, together with the GPI link Enable/
Disable setting for each bus.
4 Using any of the following methods, select what the
setting applies to. For each GPI port there can be up to
eight links.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knobs.
value
a) These include main pair numbers 1 to 300, and “Cut” and “Auto
Trans” on each bank.
5 In the <Video/Button> group, press [Select].
The selected video or button name is reflected in the
status area.
To clear a video/button name link
Make the selection to which the setting applies, then in
the <Video/Button> group press [Clear].
6 To select for each bus whether the GPI link setting is
enabled or disabled, use any of the following methods
to select the bus to which the setting applies.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
Knob
Parameter
Adjustment
Setting values
4
Bus
Bus selection
1 to maximum
value
7 In the <Bus> group, select any of the following.
Enable: Enable the GPI link setting for the selected
bus.
Setting the delay value
1 In the Switcher >Link >GPI Link >GPI Link Adjust
menu, turn the knobs to select the output port for
which you want to set the delay value, and the
corresponding delay value.
Knob
Parameter
Adjustment
Setting values
1
GPI Port
GPI output port
for the setting
1 to 8
5
Delay
Delay value for
the output port
0 to 300 (fields)
2 Press [Delay Set].
This confirms the delay value, which is reflected in the
status area.
Setting the reentry button operation mode
When you select a reentry button in the cross-point control
block of an M/E block (downstream M/E block), the
output of the upstream M/E block is read in. You can set
the system so that when a GPI link is set for the cross-point
selected on the A bus
a)
of the upstream M/E block this
triggers the GPI output.
In the Switcher >Link >GPI Link menu, set [Re-Entry
Enable] to On or Off.
When this is On, the GPI is executed upstream.
a) When the bus toggle is set to Off, the applicable bus depends on the
position of the fader lever.
Notes
• For reentry, “upstream” applies to a single stage only.
• This setting is common to all GPI output ports.
• GPI output execution on the upstream M/E block is only
possible on buses for which GPI link is set to “Enable”
in the GPI Link Adjust menu.
• GPI output occurs when you press a reentry button, the
reentry button is selected by a macro execution, or you
press the reentry button on the AUX bus remote panel.
Making a Setting for Linking Two M/
E Banks
You can link any two M/E banks for some operations by
using the Switcher >Link >M/E Link menu.
The operations for which you can link two M/E banks are
as follows.
