Chapter 3
Video Processing Flow
The switch from the current video stream (appearing on
the corresponding program monitor) to a new video stream
is referred to as a transition.
The following illustration shows the flow of operations for
carrying out a transition on an M/E bank or the PGM/PST
bank.
Select current background video (page 89)
Select next transition (page 95)
Background
Keys 1 to 8
Select new background video (page 89)
Make key settings (page 123)
Select transition type (page 95)
Cut
Mix
NAM
Super mix Preset color mix
Wipe
DME wipe
Make wipe settings
(page 163)
Make DME wipe settings
(page 187)
Preview the effect of transition (page 112)
Execute the transition (page 105)
