Chapter
1
MVS-8000X/7000X
Functions
Program output for “Main”
Background B
Background A
3D Support
Installing the switcher upgrade software in an MVS-
8000X/ 7000X, and the DME upgrade software in an
MVE-8000A, MVE-9000, or MKS-7470X/7471X,
enables the processing of video in 3D mode.
For details, see “3D Support” (page 260).
Key (Key 1 to Key 8 are
available on the main side.)
Program output for “Sub”
Background B (signal from utility 3 bus)
Background A (signal from utility 2 bus)
Key (Key 2 to Key 8 are
available on the sub side.)
For details, see “Multi Program 2” (page 253).
