You carry out independent key transition DME wipe
setting operations using the DME Wipe Adjust menu for
each keyer.
For an overview of independent key transitions, see page
113.
This section describes the independent key transition DME
wipe settings, taking the M/E-1 >Key1 >Transition >DME
Wipe Adjust menu as an example.
Basic Procedure for Independent
Key Transition DME Wipe Settings
Accessing the independent key transition
DME wipe settings menu
As an example, to access the M/E-1 >Key1 >Transition
>DME Wipe Adjust menu, carry out the following
operation.
•
In the menu control block, select the top menu selection
button [M/E 1], and select VF1 ‘Key1’ and HF6
‘Transition’ to display the Transition menu for key 1.
Next, press [DME Wipe Adjust].
If VF1 [Key5] is shown, press the switching button at the
top of the menu, so that [Key1-4] appears, and press VF1
[Key1].
Notes
To select [M/E 4] or [M/E 5], a previous button
assignment in the Setup menu is required (see page 396).
•
Press the key delegation button [Key1] in the
independent key transition control block of the M/E-1
bank, then press the independent key transition type
[DME] twice in quick succession.
Carrying out the above operation displays the M/E-1
>Key1 >Transition >DME Wipe Adjust menu (referred to
below as the Key1 DME Wipe Adjust menu).
1
In the <Pattern Select> group of the Key1 DME Wipe
Adjust menu, press [1ch] for one-channel mode or
[2ch] for two-channel mode.
The Pattern Select menu appears.
2
Select the desired DME wipe pattern group with one of
the following buttons.
In two-channel mode, only Page Turn and Page Roll
are selectable.
•
Slide/Squeeze: slide and squeeze
•
Split/Door: split and door
•
Mirror/Sphere: mirror and sphere
•
Character Trail: character trail
•
Wave/Ripple: wave and ripple
•
Page Turn/Roll: page turn and page roll
•
Frame I/O: frame in/out
•
2D Trans/3D Trans: 2D Trans and 3D Trans
•
Sparkle/Split Slide: sparkle and split slide
•
User Program: user programmable DME
For details of DME wipe patterns, see “Types of DME
Wipe Pattern” (page 183) and “DME Wipe Pattern
List” (page 361) in Appendix.
3
Press the button to select the desired pattern.
Setting Independent Key Transition
DME Wipe Modifiers
You can add modifiers such as pattern position and size for
an independent key transition DME wipe.
For introductory information, see “Setting the DME wipe
position (Positioner)” (page 189) and “Setting the DME
wipe pattern size (Size)” (page 190).
Setting the DME wipe position (Positioner)
For applicable pattern numbers, see page 185.
1
In the <Position> group of the Key1 DME Wipe
Adjust menu, press [Position], turning it on.
2
Set the following parameters.
Selecting the independent key transition
DME wipe pattern
You select the independent key DME wipe pattern from
the list of patterns displayed in the menu.
To select a DME wipe pattern for independent key1 on the
M/E-1 bank, use the following procedure.
To return the DME wipe pattern position to the
center of the screen
In the <Position> group, press [Center].
