DME Wipe Pattern Operations in the Multifunction Flexi Pad Control Block 201
Knob
Parameter
Adjustment
Setting values
1
T
Cropping ratio
of the image
from the top
–100 to +100
2
L
Cropping ratio
of the image
from the left
–100 to +100
3
R
Cropping ratio
of the image
from the right
–100 to +100
4
B
Cropping ratio
of the image
from the
bottom
–100 to +100
Knob
Parameter
Adjustment
Setting values
1
H
Horizontal
position
–200 to +200
2
V
Vertical
position
–200 to +200
3
H (R)
Relative
horizontal
movement
–400 to +400
4
V (R)
Relative
vertical
movement
–400 to +400
Knob
Parameter
Adjustment
Setting values
1
H
Cropping ratio
of the image
from left and
right sides
–100 to +100
2
V
Cropping ratio
of the image
from top and
bottom sides
–100 to +100
3
A
Cropping ratio
of the image
from all four
sides
–100 to +100
Chapter
6
DME
Wipes
Parameter group [2/2] Parameter group [2/2]
Knob
Parameter
Adjustment
Setting values
1
L
Luminance
0 to 100
2
S
Saturation
0 to 100
3
H
Hue
0 to 359
Buttons for positioning the DME wipe
pattern
POS (position): Adjusts the position of the DME wipe
pattern.
CNTR (center): Returns the DME wipe pattern position
to the center.
When you press the [POS] button, the alphanumeric
display first shows the name of the parameter, “H” or “V,”
and then the value of the parameter.
When the [POS] button is lit green, you can adjust the
position of the pattern with the control knobs.
Button for specifying effect size
SIZE: Specifies the effect size. When the [SIZE] button is
lit green, you can specify the effect size, with the
control knobs.
Knob
Parameter
Adjustment
Setting values
1
S
Effect sizes
0 to 200
a)
a) The effect size when [Size] is off is taken as 100.00.
DME wipe modify clear
With the [DME WIPE] button held down, pressing and
holding down the region selection button for the selected
region returns the DME wipe settings to their initial status.
Buttons for setting DME wipe pattern
cropping
CROP: Adjusts the DME wipe pattern cropping.
4:3 CROP: Crops a 16:9 image to 4:3.
When the [CROP] button is lit green, you can set the
cropping ratio of the DME wipe pattern, with the control
knobs.
For details of the initial status, see “Saving User-Defined
Settings” in Chapter 18 (Volume 2).
Saving, Canceling, and Deleting
DME Wipe Snapshots
Parameter group [1/2]
The operations of saving, canceling, and deleting a DME
wipe pattern snapshot you have created are the same as the
operations of saving, canceling, and deleting a wipe
snapshot (see page 182).
