Control panel configuration 1 (with standard transition modules)
Control Panel: Example Configuration 2 (With Simple Transition Modules)
The following illustration shows a typical configuration,
with simple transition modules used in the transition
control block.
Except for the simple modules, this is the same
configuration as in example configuration 1.
Transition control block and Flexi Pad control
block (simple type) (page 62)
Independent key transition control block
(simple type) (page 65)
Control panel configuration 2 (with simple transition modules)
