Copy and Swap
Target
bank
Target keyer
Target data
M/E-1
Keys 1 to 8
Key settings excluding
M/E-2
the following data items:
M/E-3
• Setup data
M/E-4
• Key snapshots
M/E-5
• Key memory
PGM/
PST
Downstream keys 1 to 8
Target
bank
Target data
M/E-1
Bank settings excluding the following data items:
M/E-2
• Setup data
M/E-3
• Flexi Pad settings
M/E-4
M/E-5
PGM/
PST
• Snapshots
• Keyframe effects
• Key snapshots
• Key memory
Chapter
8
Color
Backgrounds,
Copy
and
Swap,
and
Other
Settings
Copy and Swap
Overview of Copy and Swap
You can copy or swap the settings among the switcher
banks or between keyers.
The following settings can be copied or swapped.
• Overall settings for the M/E-1 to M/E-4, and PGM/PST
banks
• Keyer settings
• Wipe settings in a transition control block
• Wipe settings in an independent key transition control
block
• DME wipe settings in a transition control block
• DME wipe settings in an independent key transition
control block
• Matte data (color 1, color 2, and how to compose them)
• Color settings
• DME channel settings
• Format converter input settings (copy only)
• Format converter output settings (copy only)
You can carry out copy operations with a simple button
operation. Swap operations, and copy operations on DME
data can only be done with a menu operation.
M/E copy and M/E swap
You can copy and swap the overall bank settings among
the M/E-1 to M/E-5, and PGM/PST banks.
Notes
If a DME is being used on the source M/E bank, then if for
example there are insufficient DME channels, it may not
be possible to select the DME.
There are no such restrictions on a swap.
Keyer copy and keyer swap
You can carry out copy and swap operations among the
keyers listed in the following table.
Notes
If a DME is being used on the source keyer for a copy or
either keyer for a swap, then if for example there are
insufficient DME channels, or the limit on using DME
channels within an M/E bank is exceeded, it may not be
possible to select the DME.
Wipe copy and wipe swap
You can copy and swap the wipe settings among the banks
listed in the following table.
Target
bank
Target data
M/E-1
Wipe settings.
M/E-2
It is not, however, possible to carry out copy or
M/E-3
swap involving independent key transition wipe
M/E-4
settings.
M/E-5
PGM/
PST
Wipe copy and wipe swap in the
independent key transition control block
You can copy and swap the wipe settings among the keyers
listed in the following table.
Target
bank
Target keyer
Target data
M/E-1
Keys 1 to 8
Wipe settings in the
M/E-2
independent key
M/E-3
transition control block.
M/E-4
M/E-5
PGM/
PST
Downstream keys 1 to 8
DME wipe copy and DME wipe swap
You can copy and swap the DME wipe settings among the
banks listed in the following table.
