Names and Functions of Parts of the Control Panel
Chapter
2
Menus
and
Control
Panel
2
Transition control block
(compact type)
3
Device control block
(trackball)
4
Multifunction Flexi
Pad control block
1
Cross-point control block
a
Cross-point control block
For details of operations, see “Cross-Point Control
Block” (page 32) and “CCP-6224 2M/E Control Panel”
(page 71).
b
Transition control block (compact type)
For details of operations, see “Transition Control Block
(Compact Type)” (page 68).
c
Device control block (trackball)
For details of operations, see “Device Control Block
(Trackball)” (page 45).
d
Multifunction Flexi Pad control block
For details of operations, see “Multifunction Flexi Pad
Control Block” (page 73).
Cross-Point Control Block (CCP-6224/6324) in AUX Operating Mode
On the CCP6224/6324, by pressing the [AUX CTRL]
button on the 24-point cross-point control block, the button
functions are changed to functions that select AUX buses
and corresponding source signals (AUX panel-less
function).
a
AUX control block
b
AUX MIX button
c
AUX CTRL button
AUX delegation buttons
d
DEST button
AUX cross-point buttons
e
KEY button
h
Source/bus name
displays
g
A/B bus control block
f
AUX DSPLY button
a
AUX control block
This selects the AUX bus and the assigned source signals.
This cross-point control block can be switched to AUX
control mode with the [AUX CTRL] button, and the key 1
row used as AUX delegation buttons, and the key 2 row
