DME 271
Operation mode
Limits of three-dimensional
transformation parameters
Location XYZ
HD format:
–999.9999 to +999.9999
SD
format:
4:3
–333.3333 to +333.3333
16:9
–250.0000 to +250.0000
Rotation, Spin
–999.9999 to +999.9999
Axis Location
HD format:
–999.9999 to +999.9999
SD
format:
4:3
–333.3333 to +333.3333
16:9
–250.0000 to +250.0000
Location Size
0.0000 to +999.9999
Aspect
0.0000 to +2.0000
Perspective (X,
Y)
HD format:
–999.9999 to +999.9999
SD
format:
4:3
–333.3333 to +333.3333
16:9
–250.0000 to +250.0000
Perspective (Z)
0.0000 to 999.9999
Skew
–9.9999 to +9.9999
Chapter
11
DME
Operations
Operation mode
Default value
Location XYZ
0.0000
Rotation, Spin
0.0000
Axis Location
0.0000
Location Size
1.0000
Aspect
1.0000
Perspective (X, Y)
0.0000
Perspective (Z)
1.0000
Skew
0.0000
Detents
The system defines points called detents at regular
intervals on the three-dimensional space. Pressing the
[CTR] button (see page 284) in the device control block
sets the current three-dimensional parameter values to the
closest detent points.
The following table shows the interval between successive
detents for each transformation operation mode (see page
271).
Operation mode
Detent interval
Location XYZ
1.0000
Rotation, Spin
0.2500
Axis Location
1.0000
Location Size
0.2500
Aspect
1.0000
a)
Perspective (X, Y)
1.0000
Perspective (Z)
1.0000
a)
Skew
0.1000
a) When a value is smaller than 1, 1/Aspect or 1/Perspective (Z) is adjusted
to an integral value.
Three-dimensional parameter default
values
Each of the transformation operation modes has default
values for three-dimensional parameters. If required, you
can return the current value to the defaults by pressing the
[CTR] (see page 284) button in the device control block
twice in rapid succession.
The following table shows the default parameter values for
each transformation operation mode.
Resetting of parameter values set in the
source coordinate space
In some transformation operation modes, if you switch to
the target coordinate space after setting up a three-
dimensional transformation in the source coordinate space,
the setting values in the source coordinate space (three-
dimensional parameter values) are converted to values in
the target coordinate space (source/target conversion).
Once a conversion has taken place, the original source
coordinate space parameters do not return to their original
values when you switch back to the source coordinate
space. They are reset to zeros.
Source/target conversion occurs in the following operation
modes:
• Location XYZ
• Rotation
Transformation Operation Modes
The following operation modes are available for three-
dimensional DME transformations. These operations are
carried out in the device control block (trackball or
joystick). For details, see “Three-Dimensional
Transformation Operations” (page 283).
Location XYZ
Moves the image on the X-axis, Y-axis, or Z-axis. The
direction of movement differs depending on whether you
are manipulating the image in the source coordinate space
or the target coordinate space.
