Chapter
11
DME
Operations
Image movement in the source coordinate space Image rotation in the target coordinate space
Movement on the X-axis Movement on the Y-axis
Movement on the Z-axis
Rotation around the X-axis
Rotation around the Z-axis
Rotation around the Y-axis
Image movement in the target coordinate space
Movement on the X-axis Movement on the Y-axis
Movement on the Z-axis
Spin
When rotating the image in Rotation mode, it may not
always be possible to achieve the kind of rotation around
an axis that you want. Combining Rotation mode with Spin
mode creates an effect that rotates the image around a
specified axis. The type of rotation differs depending on
whether you are manipulating the image in the source
coordinate space or the target coordinate space. The way
the image rotates around an axis is the same as in Rotation
mode.
Axis location
Moves an axis of rotation in the source coordinate space.
Axis movement
Rotation
Rotates the image on the X-axis, Y-axis, or Z-axis. The
type of rotation differs depending on whether you are
manipulating the image in the source coordinate space or
the target coordinate space.
Image rotation in the source coordinate space
Movement on the X-axis Movement on the Y-axis
Rotation around the X-axis
Rotation around the Z-axis
Rotation around the Y-axis
Movement on the Z-axis
Location size
Changes the size of the whole image.
•
Because shrinking and magnification of the image in the
source coordinate space is done in three-dimensional
space, magnifying the image emphasizes the sense of
perspective.
