USO RESTRITO
30
Names and Functions of Parts of the Control Panel
Chapter
2
Menus
and
Control
Panel
Menus and Control Panel
Chapter 2
Names and Functions of Parts of the Control Panel
The maximum number of M/E banks supported by the
MVS-8000X/7000X system is given below.
MVS-8000X
Five M/E banks maximum (PGM/PST, M/E-1 to M/E-4)
MVS-7000X
Six M/E banks maximum (PGM/PST, M/E-1 to M/E-5)
Notes
On the MVS-8000X, M/E-5 cannot be used. M/E-5
operation and settings are disabled, even if they appear
in the menu.
See “Disabled Operation and Settings Menus” (page
393) in Appendix.
To select M/E-4 or M/E-5 using control panel buttons, it
is first necessary to assign the buttons in the Setup menu.
For details of assignment, see “Assigning a Button for
M/E-4 or M/E-5 Selection in the Setup Menu” (page
396) in Appendix.
Control Panel: Example Configuration 1 (With Standard Transition Modules)
The MVS-8000X/7000X system control panel comprises a
number of modules.
The following illustration shows a typical 32-button, 4-M/
E configuration, with standard transition modules used in
the transition control block.
