Overall Control Panel Settings (Config Menu) 573
Chapter
19
Control
Panel
Setup
(Panel)
Knob
Parameter
Adjustment
Setting values
1
Bank
Bank selection
1 to 6
4 In the <PRE MCRO/POST MCRO> group, select
[Dual Bkgd Bus].
This assigns the dual background mode to the [PRE
MCRO] button, and disables the [POST MCRO]
button.
Assigning the Utility/Shotbox Mode
Switching Function
You can first assign functions to the key 2 row cross-point
buttons, and then use them in the same way as the buttons
in the utility/shotbox control block.
To switch this mode on and off, it is necessary to assign
this function to the cross-point control block [PRE
MCRO] button (see page 597).
1 In the Panel >Config menu, press [Link/Program
Button].
The Link/Program Button menu appears.
2 Press [Xpt Module].
The Xpt Module menu appears.
3 Using any of the following methods, select the bank.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
Knob
Parameter
Adjustment
Setting values
1
Bank
Bank selection
1 to 6
4 Select [Utility/Shotbox] in the <PRE MCRO/POST
MCRO> group.
This assigns the utility/shotbox mode to the [PRE
MCRO] button, and disables the [POST MCRO]
button.
Assigning the Function to Disable
Cross-Point Button Operations to a
Button
1 In the Panel >Config menu, press [Link/Program
Button].
The Link/Program Button menu appears.
2 Press [Xpt Module].
The Xpt Module menu appears.
3 Using any of the following methods, select the bank.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
Knob
Parameter
Adjustment
Setting values
1
Bank
Bank selection
1 to 6
4 Press [Inhibit Set] in the <PRE MCRO/POST
MCRO> group.
This assigns the function to disable cross-point button
operations to the [PRE MCRO] button.
Assigning the AUX Bus Control
Mode Switching Function
You can switch the cross-point control block of the CCP-
6224/6324 control panel to AUX bus control mode (AUX
panel-less function). You can display the names of the
sources or buses for the AUX buses in the source name
displays.
The function for switching to AUX control (AUX Ctrl)
mode is assigned to the [PRE MCRO] button. And the
function for switching the source name displays to the
names of the sources or buses for the AUX buses is
assigned to the [POST MCRO] button.
1 In the Panel >Config menu, press [Link/Program
Button].
The Link/Program Button menu appears.
2 Press [Xpt Module].
The Xpt Module menu appears.
3 Using any of the following methods, select the bank.
• Press directly on the list in the status area.
• Press the arrow keys to scroll the reverse video
cursor.
• Turn the knob.
Knob
Parameter
Adjustment
Setting values
1
Bank
Bank selection
1 to 6
4 Select [Aux Ctrl/Aux Disply] in the <PRE MCRO/
POST MCRO> group.
This assigns the Aux Ctrl function to the [PRE
MCRO] button, and the Aux Display function to the
[POST MCRO] button.
