About the Macro Attachment List Display 673
UTIL1 Bus
UTIL2 Bus
EXT DME Bus
DMEUtility1
DMEUtility2
Sub UTIL1 Bus
Sub UTIL2 Bus
Sub EXT DME Bus
Main&Sub UTIL1 Bus
Main&Sub UTIL2 Bus
Main&Sub EXT DME Bus
Dual A Bus
Dual B Bus
Sub Dual A Bus
Sub Dual B Bus
Main&Sub Dual A Bus
Main&Sub Dual B Bus
About the Macro
Attachment List Display
The Button column in the macro attachment list displayed
in the status area of the Macro >Attachment menu screen
shows character strings which identify macro attachment
assigned buttons. Each of these character strings is in fact
a combination of characters shown in the Button (1),
Button (2), and Button (3) columns in the following tables.
For example, if Block and Button (1) to Button (3) are
combined as:
Block: P/P XPT
Button(1): UTIL1 Bus
Button(2): V
Button(3): XPT2
The Button column in the macro attachment list in the
Macro >Attachment menu screen shows “UTIL1 Bus V
XPT2,” which means “utility 1 bus, video signal, cross-
point number 2.”
M/E and PGM/PST Banks
The following table shows only the macro attachment
assignable buttons in the PGM/PST bank.
For the M/E-1 (M/E-2 to M/E-5) bank, “P/P” in the Block
Select and Block columns changes to “M/E-1” (“M/E-2”
to “M/E-5”) and “DSK” in the Button (1) and Button (2)
columns changes to “KEY.” The contents of the Button (3)
column do not change.
Block Select: P/P, Block: P/P XPT
A Bus
B Bus
DSK1 Bus
:
DSK8 Bus
XPT 1
:
XPT 128
M/E 1
M/E 2
M/E 3
P/P
DSK1 Src Bus
:
DSK8 Src Bus
