Resizer DME Wipe Setting 195
Resizer DME Wipe Setting
You can carry out a DME wipe on a key using the resizer.
Notes
When the screen aspect ratio is 4:3 in HD format, when the
resizer DME wipe is used to shrink a video image, this is
applied to the 16:9 screen including the added video on the
left and right sides. Use the crop function as required to
extract the 4:3 image.
DME wipe patterns available for resizer DME wipe
You can use the following patterns of the DME wipe
pattern one-channel mode that can be used in a resizer
DME wipe (7000-series numbers).
•
Slide (pattern numbers: 7001 to 7008)
•
Squeeze (pattern numbers: 7021 to 7031)
•
Frame in-out (pattern numbers: 7201 to 7208, 7221 to
7224)
Relation between resizer DME wipes and
other effects
The following relations hold between a resizer DME wipe
and other effects.
Relation to processed keys
It is not possible to select a resizer DME wipe for a key
with processed key enabled.
Relation to resizer
It is not possible to use a resizer DME wipe for a key with
resizer enabled.
It is not possible to use a resizer DME wipe for a key
forming a pair with a key with the dual resizer effect
enabled. The key combinations forming pairs are keys 1
and 2, keys 3 and 4, key 5 and key 6, and key 7 and key 8.
For example, when a dual resizer effect is enabled for key
1, it is not possible to use a resizer DME wipe on key 2.
Making resizer DME wipe settings
1
In the <Pattern Select> group of the Key1 DME Wipe
Adjust menu, press [1ch].
The 1ch Pattern Select menu appears.
2
Select [Resizer Slide/Squeeze] or [Resizer Frame I/O].
The patterns of the selected group appear.
The wipe patterns that can be used for a resizer DME
wipe are as follows.
•
Slide (pattern numbers: 7001 to 7008)
•
Squeeze (pattern numbers: 7021 to 7031)
•
Frame in-out (pattern numbers: 7201 to 7208, 7221
to 7224)
3
Press the desired pattern to select it.
For more about resizer DME wipe modifiers, see
“Setting Independent Key Transition DME Wipe
Modifiers” (page 193).
