Setting data and LCD displays for the following panel
buttons
• Key Control Block:
Delegation buttons, [AUTO DELEG]
• Numeric Keypad Control Block:
Mode selection buttons, [TC], [RCALL], [STORE]
• Menu Control Block:
User preference buttons assigned for Plug-in Editor
Enbl and System Manager Enbl functions
• [SUB MENU SITE]
• Utility/Shotbox Control Block:
[BANK1] to [BANK4], memory recall button
• Downstream Key Control Block:
[DSK1] to [DSK4], [K-SS], key source name display/key
snapshot buttons
• Device Control Block: [RSZR], [ASP], [LOC]
• Cross-Point Control Block:
[KEY3], [KEY4], Delegation buttons for bus assigned to
key 1 row, [DSPLY], [DEST], [KEY], [SHIFT], [UTIL],
[MCRO ATTCH ENBL], [DUAL BKGD BUS], [UTIL/
SBOX]
• Keyframe Control Block:
[EDIT ENBL]
• Auxiliary Bus Control Block:
Bus delegation buttons, [SHIFT], [DEST], [2ND], [KEY],
[RTR], [LEVEL1] to [LEVEL4]
• Transition Control Block (standard type):
[SHIFT], [ADD], [KEY1] to [KEY8], [K-MOD ENBL], [K-
TR ENBL], [K-SS], key source name display/key
snapshot buttons
• Flexi Pad Control Block:
[WIPE], [DME], [SNAPSHOT], [EFF], [SHOTBOX],
[MCRO], [TRANS RATE], [BANK0], [BANK1], memory
recall buttons
• Transition Control Block and Flexi Pad Control Block
(simple type):
[WIPE], [DME], [SNAPSHOT], [INH], memory recall
section
• Independent Key Transition Control Block (simple type):
[K-SS], [K-SS3/4], [KEY1] to [KEY8], key source name
display/key snapshot buttons
• Downstream Key/Fade-to-Black Control Block:
[DSK1], [DSK2], [K-SS], key source name display/key
snapshot buttons, Edit PVW Shift ON/OFF
• Multifunction Flexi Pad Control Block:
[WIPE], [DME WIPE], [SNAPSHOT], [EFF],
[SHOTBOX], [MCRO], [TRANS RATE], [KEY ADJ],
[KEY SS], memory recall buttons
To Next Page
