Interfacing With External Devices (Device Interface Menu) 639
Chapter
21
DME
Setup
(DME)
3
To apply the selection made in step 2 when the input
is high, press [H Set]. To apply the selection made in
step 2 when the input is low, press [L Set].
This confirms the setting, which appears in the status
area.
Making DME GPI Output Settings
1
In the DME >Device Interface menu, press [DME1
GPI Output].
The DME1 GPI Output menu appears.
The output port selection is fixed at 1.
2
In the <Trigger Type> group, select the trigger
polarity.
Status: The relay opens/closes or the output goes
high/low level in response to the status.
No Operation: The trigger has no effect on the relay
state or output level.
3
Using any of the following methods, select the action
you want to set.
•
Press directly on the list in the status area.
•
Press the arrow keys to scroll the reverse video
cursor.
•
Turn the knob.
a) Error Make, Error Break, No Action
4
Press [Action Set] to confirm the action selection.
The selected setting appears in the status area.
