Applying Special Effects (Effects on the Overall Video Signal)
Knob
Parameter
Adjustment
Setting values
1
Mix
Mix amount
for Sketch
video and
input video
0.00 to 100.00
a)
2
Clip
Reference
level for
outline
extraction
–100.00 to
+100.00
b)
3
Gain
Image gain
for outline
extraction
–100.00 to +100.00
4
C Gain
Chroma gain
of input video
–100.00 to +100.00
Knob
Parameter
Adjustment
Setting values
1
H
Simultane-
ously adjust
the left and
right resolu-
tion
0.00 to 100.00
2
V
Simultane-
ously adjust
the top and
bottom
resolution
0.00 to 100.00
3
All
Simultane-
ously adjust
the resolu-
tion of all four
sides
0.00 to 100.00
5
Coring
Minimum
value of
edge to
emphasize
0.00 to 100.00
Knob
Parameter
Adjustment
Setting values
1
Mix
Mix amount
for Draw
video and
input video
0.00 to 100.00
a)
2
Clip
Reference
level for
outline
extraction
–100.00 to
+100.00
b)
3
Gain
Image gain
for outline
extraction
–100.00 to +100.00
3
Select the method for applying outlines in the <Sketch
Mode> group.
Sketch: Apply an effect like a sketch.
Edge Color: Enhance the outlines.
Draw: Apply an effect like a line drawing.
Relief: Apply a bas-relief effect.
Sharp: Increase the apparent sharpness.
4
Set the following parameters, according to the method
selected in step 3.
When Sketch is selected
Chapter
11
DME
Operations
a) 100.00 gives an image completely transformed by the Sketch effect.
0.00 is the original input image.
b) The larger the Clip value, the narrower the outline width.
When Relief is selected
Knob
Parameter
Adjustment
Setting values
1
Mix
Mix amount
for Relief
video and
input video
0.00 to 100.00
a)
2
Offset
Relief
luminance
level
–100.00 to +100.00
3
Gain
Image gain
for outline
extraction
–100.00 to +100.00
4
Angle
Direction of
relief image
light source
–8.00 to +8.00
a) 100.00 gives an image completely transformed by the Sketch effect.
0.00 is the original input image.
When Sharp is selected
a) 100.00 gives an image completely transformed by the Sketch effect.
0.00 is the original input image.
b) The larger the Clip value, the narrower the outline width.
When Edge Color is selected
Knob
Parameter
Adjustment
Setting values
1
Mix
Mix amount
for Edge
Color video
and input
video
0.00 to 100.00
a)
2
Clip
Reference
level for
outline
extraction
–100.00 to
+100.00
b)
a) 100.00 gives an image completely transformed by the Sketch effect.
0.00 is the original input image.
b) The larger the Clip value, the narrower the outline width.
When Draw is selected
5 If you selected other than “Sharp” in step 3, depending
on the necessity, proceed as follows.
To adjust the outline color for Edge Color or Draw
Turn [Edge Matte] on and set the following parameters
to set the outline color.
Knob
Parameter
Adjustment
Setting values
1
Luminance
Luminance
0.00 to 100.00
2
Saturation
Saturation
0.00 to 100.00
3
Hue
Hue
359.99 to 0.00
