Configuring ACL ACL Configurations
Configuration Guide
529
Step 4 end
Return to privileged EXEC mode.
Step 5 copy running-config startup-config
Save the settings in the configuration file.
The following example shows how to bind ACL 1 to port 3 and ACL 2 to VLAN 4:
Switch#configure
Switch(config)#interface gigabitEthernet 1/0/3
Switch(config-if)#access-list bind acl 1
Switch(config-if)#exit
Switch(config)#interface vlan 4
Switch(config-if)#access-list bind acl 2
Switch(config-if)#show access-list bind
Index Policy Name Interface/VID Direction Type
----- ----------- ------------- -------- ----
Index ACL ID Interface/VID Direction Type
----- ----------- ------------- -------- ----
1 1 Gi1/0/3 Ingress Port
2 2 4 Ingress Vlan
Switch(config-if)#end
Switch#copy running-config startup-config
Policy Binding
You can bind the Policy to a port or a VLAN, then the received packets will be matched and
operated based on the Policy.
Step 1 configure
Enter global configuration mode
