Chapter 1: DDR3 and DDR2 SDRAM Memory Interface Solution
ODT_MAP
Bank and byte lane
position information for
the ODT. This parameter
is referred to as one of
the Address/Control byte
groups. See
ADDR_MAP
description. This
parameter varies based
on the pinout and should
not be changed manually
in generated design.
See the ADDR_MAP example.
CS_MAP
Bank and byte lane
position information for
the chip select. See the
ADDR_MAP description.
This parameter varies
based on the pinout and
should not be changed
manually in generated
design.
See the ADDR_MAP example.
PARITY_MAP
Bank and byte lane
position information for
the parity bit. Parity bit
exists for RDIMMs only.
See the ADDR_MAP
description. This
parameter varies based on
the pinout and should not
be changed manually in
generated design.
See the ADDR_MAP example.
RAS_MAP
Bank and byte lane
position information for
the RAS command. See the
ADDR_MAP description.
This parameter varies
based on the pinout and
should not be changed
manually in generated
design.
See the ADDR_MAP example.
WE_MAP
Bank and byte lane
position information for
the WE command. See the
ADDR_MAP description.
This parameter varies
based on the pinout and
should not be changed
manually in generated
design.
See the ADDR_MAP example.
Table 1-66: DDR2/DDR3 SDRAM Memory Interface Solution Pinout Parameters (Cont’d)
Parameter Description Example
