Chapter 1: DDR3 and DDR2 SDRAM Memory Interface Solution
Debugging DDR3/DDR2 Designs
Calibration failures and data errors can occur for many reasons and the debug of these
errors can be time consuming. This section is intended to provide a clear step-by-step
debug process to quickly identify the root cause of the failure and move to resolution.
To focus the debug of calibration or data errors, use the provided MIG Example Design on
the targeted board with the Debug Feature enabled through the MIG 7 series GUI. The
latest MIG 7 series release should be used to generate the Example Design.
Finding Help on Xilinx.com
To help in the design and debug process when using the MIG IP core, the Xilinx Support
web page contains key resources such as product documentation, release notes, answer
records, information about known issues, and links for obtaining further product support.
Documentation
This product guide is the main document associated with the MIG IP core. This guide, along
with documentation related to all products that aid in the design process, can be found on
the Xilinx Support web page
or by using the Xilinx Documentation Navigator.
Download the Xilinx Documentation Navigator from the Downloads page
. For more
information about this tool and the features available, open the online help after
installation.
Solution Centers
See the Xilinx Solution Centers for support on devices, software tools, and intellectual
property at all stages of the design cycle. Topics include design assistance, advisories, and
troubleshooting tips.
The Solution Center specific to the MIG IP core core is located at the Xilinx MIG Solution
Center.
Answer Records
Answer Records include information about commonly encountered problems, helpful
information on how to resolve these problems, and any known issues with a Xilinx product.
Answer Records are created and maintained daily ensuring that users have access to the
most accurate information available.
