Chapter 4: LPDDR2 SDRAM Memory Interface Solution
Simulation Flow Using IES and VCS Script Files
To run the simulation, go to this directory:
<project_dir>/<Component_Name>_ex/imports
For a project created with the name set as project_1 and the Component Name entered
in Vivado IDE as mig_7series_0, go to the directory as follows:
project_1/mig_7series_0_ex/imports
IES and VCS simulation scripts are meant to be executed only in Linux operating systems.
The ies_run.sh and vcs_run.sh files are the executable files for running simulations
using IES and VCS simulators respectively. Library files should be added to the
ies_run.sh and vcs_run.sh files respectively. See the readme.txt file for details
regarding simulations using IES and VCS.
