Chapter 1: DDR3 and DDR2 SDRAM Memory Interface Solution
<component name>/example_design/sim
Table 1-4 lists the modules in the example_design/sim directory.
<component name>/user_design
The user_design folder contains the following:
• rtl and xdc folders
• Top-level wrapper module <component_name>.v/vhd
• Top-level modules <component_name>_mig.v/vhd and
<component_name>_mig_sim.v/vhd
The top-level wrapper file <component_name>.v/vhd has an instantiation of top-level
file <component_name>_mig.v/vhd.
Top-level files <component_name>_mig.v/vhd and
<component_name>_mig_sim.v/vhd have the same module name as
<component_name>_mig. These two files are same in all respects except that the file
<component_name>_mig_sim.v/vhd has parameter values set for simulation where
calibration is in fast mode viz., SIM_BYPASS_INIT_CAL = "FAST" etc.
IMPORTANT: The top-level file <component_name>_mig.v/vhd is used for design synthesis and
implementation, whereas the top-level file <component_name>_mig_sim.v/vhd is used in
simulations.
The top-level wrapper file serves as an example for connecting the user_design to the
MIG core.
Table 1-4: Files in example_design/sim Directory
Name Description
ddr2_model.v
ddr3_model.v
These are the DDR2 and DDR3 SDRAM models.
ddr2_model_parameters.vh
ddr3_model_parameters.vh
These files contain the DDR2 and DDR3 SDRAM model parameter setting.
ies_run.sh
(1)
Linux Executable file for simulating the design using IES simulator.
vcs_run.sh
(1)
Linux Executable file for simulating the design using VCS simulator.
readme.txt
(1)
Contains the details and prerequisites for simulating the designs using Mentor
Graphics Questa Advanced Simulator, IES, and VCS simulators.
sim_tb_top.v This is the simulation top file.
Notes:
1. The ies_run.sh and vcs_run.sh files are generated in the folder mig_7series_0_ex/imports when the example design is
created using Open IP Example Design for the design generated with Component Name entered in Vivado IDE as
mig_7series_0.
