Dolby Laboratories IMS2000 - Adding a JNIOR Device

Dolby
®
IMS2000 Installation and User’s Manual
IMS.OM.004730.DRM Issue 3 103
13.3.7 Adding a JNIOR Device
To add the JNIOR device:
1. Click on the
New button in the Device Manager window.
The
New Device drop-down window appears.
2. Select
JNior.
The
Device Manager GUI updates to reflect the addition of the JNIOR device.
3. Input the JNIOR server IP address in the appropriate field.
The port number field will already contain the appropriate value (factory default
value).
Note:
The JNIOR device documentation will provide the correct user name and
password (factory default values).
4. Click the
Save button to save the settings.
A window appears asking for a password.
5. Enter the password to proceed.
Clicking the
Revert button prior to saving will delete the unsaved information.
Figure 13-22 JNIOR Added
Removing a JNIOR Device
To remove the JNior device:
1. Select the device in the
Device Manager GUI.
2. Click on the
Delete Device button.
IP address
