Dolby Laboratories IMS2000 - Installation and Power-Up Sequence; Device Manager Configuration

276 Dolby
®
IMS2000 Installation and User’s Manual
IMS.OM.004730.DRM Issue 3
18.2 Installation and Power-Up Sequence
To complete the installation:
1. Verify that both projectors and the IMS2000s are turned off.
2. Install the IMS2000 security manager in the primary projector.
3. Install the IMS2000 link decryptor in the secondary projector.
4. Connect Ethernet cables to both projectors and the IMS2000, and verify that they are
on the same network.
5. Connect BNC cables A and B from the primary projector SDI output connectors to the
secondary projector SDI input connectors.
To complete the power-up sequence:
1. Power up the primary projector.
2. Power up the secondary projector.
3. Wait until both projectors are completely powered up.
4. Power up the IMS2000.
18.3 Device Manager Configuration
To configure the IMS2000 to operate in a dual-IMB setup:
1. Select
Administration > Device Manager.
2. Click on the
New button to add the primary projector (security manager) in the Device
Manager
application.
3. Set the primary projector (security manager) configuration:
a. Set the identifier: Primary projector plus the name of the projector.
b. Select the projector model from the drop-down menu.
c. Specify the head IP of the projector.
d. Select
Yes for the primary projector.
e. Select the dual-projector check box.
f. For 2D presentations, select
Full from the Display drop-down menu.
Note:
For HFR 3D setups, select Left from the display mode drop-down menu.
4. Click on the
Save button.
5. Enter the appropriate credentials.
