4.12 GPO
• General purpose output for automation interface
• RJ-45 connector
Table 4-2 GPO Pin Number and Description
Note:
GPO 5 can be configured for LTC output via an internal jumper.
4.13 AES Out 1–8
• Digital audio channels 1–8 output
• RJ-45 connector
Table 4-3 AES-Out 1–8 Pin Number and Description
•
Pin Number Description
1 GPO 0
2 GPO 1
3 GPO 2
4 GPO 4
5 GPO 5
6 GPO 3
7 +5 VDC
8 Ground
Pin Number Description
1 Channel 1 and 2 plus
2 Channel 1 and 2 minus
3 Channel 3 and 4 plus
4 Channel 5 and 6 plus
5 Channel 5 and 6 minus
6 Channel 3 and 4 minus
7 Channel 7 and 8 plus
8 Channel 7 and 8 minus
