IMS2000 Installation and User’s Manual
IMS.OM.004730.DRM Issue 3 105
13.3.9 Adding 3D Systems
You will have the option to add 3D systems. When using an IMS2000 configuration for
3D presentation, the projector needs to be set to the proper color space. Contact the
projector vendor to configure the projector properly.
Dolby 3D Support
To enable the Dolby
®
3D support, please contact Dolby product specialists to receive the
appropriate license (See Section 1.3).
RealD 3D Support
To enable the RealD 3D support, please contact RealD at mailto:cinema-support@reald.com
to receive the appropriate license.
To add Real 3D support:
1. Open the
Device Manager GUI; select Administration > Device Manager.
2. Click on the
New Device button.
3. Select the
RealD 3D EQ.
The device will be visible on the main
Device Manager GUI.
4. Click on the
Save button.
Enter the appropriate password, and click
Ok. Clicking the Revert button prior to
saving will delete the unsaved information.
Sensio 3D Support
To enable the Sensio 3D support, please contact Dolby product specialists to receive the
appropriate license (See Section 1.3) .
13.3.10 Closed Caption Support
To enable CaptiView and Rear Window devices closed caption support, install the
appropriate license. For information about the closed caption Support, contact Dolby
product specialists (see 1.3) or visit
http://www.doremilabs.com/support/cinema-
support/cinema-manuals/captiview-manuals/.
13.3.11 Configuring the Subtitle Engine
This section provides instructions on how to set up the Device Manager for subtitle
engine support. It will allow you to generate subtitles into the picture before being
exported to the projector. To configure the subtitle engine:
1. Open the
Device Manager GUI; select Administration > Device Manager.
2. Click on the
New Device button.
The
New Device drop-down window appears.
