Dolby
®
IMS2000 Installation and User’s Manual
IMS.OM.004730.DRM Issue 3 275
Chapt er 1 8 Installing and Configuring a Dual-
Projector Setup
This chapter provides step-by-step instructions for installing and configuring two
IMS2000s for a dual-projector setup. It also explains how to create a basic playlist.
In a dual projector IMS2000 setup, the two boards are identical regarding firmware and
software but differ in regards to serialization. The primary IMS2000, referred to as the
IMS2000-SM (security manager) in a dual projector configuration, is interchangeable
with a standard IMS2000 and can be used in a single projector setup.
The secondary IMS2000, the IMS2000-LD (link decryptor), does not require storage for
and ships without hard drives. It is serialized differently in the factory which enables the
unit to operate as the secondary in a dual projector setup. This IMS2000 can only be used
as the link decryptor board and cannot be changed to become a standard IMS2000 or
IMS2000-SM.
In this section, the primary IMS2000 is referred to as the security manager, and the
secondary as the link decryptor.
®
3D is not yet supported in dual IMS2000 setups.
18.1 Required Materials
The following materials are required to complete the installation:
• IMS2000 security manager (quantity: 1)
• IMS2000 link decryptor (quantity: 1)
• Series 2 digital cinema projectors (quantity: 2)
We recommend using the same projector type and model for both IMS2000s.
• KDM for dual projection (quantity: 1)
