174 Dolby
®
IMS2000 Installation and User’s Manual
IMS.OM.004730.DRM Issue 3
13.23 Adding an Audio Processor to the IMS2000
To add a Dolby audio processor to the IMS2000 as a RAW device (to enable automation
commands):
1. Select Administration > Device Manager.
2. Click the New button.
3. Select
Raw Device.
4. Enter the name of the Dolby Audio Processor (for example, CP650, CP750, or CP850)
in the
Identifier field.
5. Enter
Dolby in the Vendor field.
6. Enter the name of the Dolby audio processor (for example, CP650, CP750, or CP850)
in the
Product Name field.
7. Enter the IP address of the device in the
Device IP field.
8. Enter the protocol type in the
Protocol field.
9. Enter the appropriate port number in the
Port field as follows:
• Dolby CP850 port number: 61408
• Dolby CP750 port number: 61408
• Dolby CP650 port number: 61412
13.24 Transferring the Automation Cue Library to the IMS2000
To transfer the audio processor automation cue library to the IMS2000 (so it appears in
the
Device Manager Library list):
1. Use FileZilla (or another FTP client program) on your computer.
2. Connect to the IMS2000 using the following credentials:
•
Username: root
• Password: ask you administrator
• Port: 22
3. Browse to doremi/etc/cuelib.
4. Transfer the Dolby
audio processor cues library file into this directory.
13.25 Adding the Dolby Audio Processor Macro and Automation
Cues to the IMS2000
To add macro and automation cues:
1. Select
Administration > Device Manager.
2. Click the New button.
3. Click
Select and Action to Insert > Library, then select Insert.
4. Select the audio processor from the
Driver field.
5. Select the cue you want to trigger in the
Action field.
