Dolby

IMS2000 Installation and User’s Manual

IMS.OM.004730.DRM Issue 3 11

4.11 GPI

• General purpose input for automation interface

• RJ-45 connector

Table 4-1 GPI Pin Number and Description

Pin Number Description

1 GPI 0+

2 GPI 0–

3 GPI 1+

4 GPI 2+

5 GPI 2–

6 GPI 1–

7 GPI 3+

8 GPI 3–
