Dolby Laboratories IMS2000 - Chapter 23 25-Pin D-Connector to Dual RJ-45 Adapter Pinouts

Dolby
®
IMS2000 Installation and User’s Manual
IMS.OM.004730.DRM Issue 3 299
Chapt er 2 3 25-Pin D-Connector to Dual RJ-45 Adapter
Pinouts
The following table shows the pinouts for the 25-pin D-connector to dual RJ-45 adapter.
Table 23-1 25-Pin D-Connector to Dual RJ-45 Adapter Pinouts
AES Pair To
1+ (channel 1/2+)
P14
1– (channel 1/2–)
P2
2+ (channel 3/4+)
P3
3+ (channel 5/6+)
P17
3– (channel 5/6–)
P5
2– (channel 3/4–)
P16
4+ (channel 7/8+)
P6
4– (channel 7/8–)
P19
5+ (channel 9/10+)
P8
5– (channel 9/10–)
P21
6+ (channel 11/12+)
P22
7+ (channel 13/14+)
P11
7– (channel 13/14–)
P24
6– (channel 11/12–)
P10
8+ (channel 15/16+)
P25
8– (channel 15/16–)
P13
