7.2 Installing Hard-Disk Drives
Hard-disk drives are shipped out of their chassis. Upon initial installation, insert each
drive into the IMS2000 hard-disk drives chassis carrier prior to powering up the
projector. Do not insert or remove hard-disk drives if the unit is powered on. hard-disk
drives must be of the same make and model with the storage capacity. Dolby prohibits
mixing SATA I drives with SATA II drives within the same RAID.
Each hard-disk drive has a silver latch mechanism that enables you to unlatch the drive
from the hard drive cage.
1. Release the lever of the hard-disk drive carrier by pressing the release tab.
Figure 7-6 Silver Latch on Hard-Disk Drive
2. Insert each hard-disk drive into the hard-disk drive slot with the handle open.
3. Push the handle in until it locks into place.
